Our work, as we left it.

Panels, conduit, cameras, readers and gates from our own jobs. Nothing here is stock. Each photo is cropped to show the work and not the building, and no client is named.

Panels and head-end

Controllers, power supplies, batteries and rack equipment, mounted, wired by function and labelled.

Access ControlIntrusion Alarms

Open enclosure with a door controller, power supplies, output boards and two batteries, status lights on.
Door controller, power supplies and battery backup in one enclosure.
Two door controllers in an enclosure with wire duct, a printed label at every door's wiring.
Two controllers in wire duct, every door's wiring labelled.
Door controller in an enclosure, its field wiring bundled and tied down one side.
Door controller with the field wiring dressed down one side.
Single door controller in a black enclosure, its wiring tied to mounts around the board.
Door controller, wiring routed on tie mounts.
Enclosure on a plywood backboard with two door controllers, conduit entering from above.
Two controllers and their power distribution, fed by conduit from above.
Coloured conductors landed on the terminal blocks of a controller module.
Conductors terminated on a controller module.
Close view of a controller board with twisted pairs tied along its edge.
Twisted pairs dressed along a controller board.
Power supply above a fused distribution board in an enclosure.
Power supply and fused outputs for door hardware.
Compact door controller in a wall enclosure fed by conduit from above.
Compact controller in a conduit-fed enclosure.
Four controller boards and two batteries in a large enclosure.
Multi-board enclosure with dual batteries, wiring routed by function.
Enclosure with a controller board and a small network device.
Controller and network device in a compact enclosure.
Open red enclosure with two circuit boards, dressed wiring and two batteries.
Control enclosure with boards, dressed wiring and battery backup.
Alarm board and power supply in an open enclosure, conductors dressed to the terminals.
Alarm board and supply, conductors terminated and dressed.
Video encoders in a rack beside yellow fibre patch cords.
Encoders and fibre patch cords in the rack.

Conduit and pathway

Conduit bent and run on site, from the head-end out to each device.

Structured Cabling

A bank of parallel conduits with matching offsets running down a concrete wall to enclosures.
Conduit bank with matched offsets, down to the enclosures.
Surface conduit running down a block wall from a junction box to a keypad beside a door.
Conduit drop to a keypad.
Conduit and a junction box above a door, feeding the lock at the head of the frame.
Conduit to the door hardware at the head of a frame.
Two weatherproof junction boxes on a stone wall with flexible conduit to a fence post.
Weatherproof junction boxes at a fence line.

Doors and readers

Readers, keypads, intercoms and the hardware on the door itself.

Access ControlIntercom & Entry

Intercom station, reader and accessible push buttons in a vestibule.
Vestibule intercom, reader and accessible push buttons.
Keypad reader on a ribbed concrete wall beside a steel door frame.
Keypad reader at an exterior door.
Card reader beside an accessible push button at a door.
Card reader with an accessible door operator button.

Cameras and sensors

Cameras mounted and aimed inside and out, and the detectors that go with them.

Video SurveillanceIntrusion Alarms

Camera on a pendant mount at the corner of a shingled roof.
Exterior camera on a pendant mount at a roof corner.
Multi-sensor camera on a wall arm against dark metal cladding.
Multi-sensor camera on a wall arm.
Multi-sensor camera under the corner of a glazed canopy.
Multi-sensor camera at a building corner.
Camera on a conduit drop from the roof trusses of a warehouse.
Camera on a conduit drop in a high-bay warehouse.
Dome camera at the ceiling line of a red interior wall.
Interior dome camera.
Camera in the corner of a block wall, fed by surface conduit.
Camera fed by surface conduit.
Motion detector mounted high in the corner of a room.
Corner-mounted motion detector.

Gates and yards

Readers, intercoms, cameras and operator wiring at vehicle and pedestrian gates.

Gates & Vehicle Access

Pedestal at a vehicle entrance with intercom stations at car and truck height, between two bollards.
Gate pedestal with stations at car and truck height.
Open control box of a gate operator beside a chain-link gate.
Gate operator control wiring.
Card reader on the post of a chain-link pedestrian gate.
Card reader on a gate post.
Dome camera on a steel arm bolted to a yellow bollard at a vehicle lane.
Dome camera on a bollard-mounted arm at a vehicle lane.
